Description

Load cells are transducers that convert force or weight into an electrical signal. The Keli digital load cell, like other load cells, is commonly used in industrial applications for measuring force, weight, or pressure.

• Keli digital load cells provide digital output signals, which can simplify data processing and communication with digital systems such as microcontrollers or computers.
• Digital load cells offer high resolution, allowing for precise measurement of small changes in force or weight.
• Weight Capacity Available in 30 Ton & 40 Ton.
• High accuracy and repeatability, ensuring reliable and consistent measurement performance over time.
• Keli load cells are designed for easy installation and integration into existing systems, with standardized mounting holes or interfaces.
• Constructed with high-quality alloy steel, ensuring durability and longevity even in harsh industrial environments.
• Sealed to protect the internal components from dust, moisture, and other contaminants, ensuring reliable performance in challenging conditions.

Specifications

• Rated Capacity: 30ton to 40ton
• Rated output: 2.0±0.002mv/v
• Hysteresis Error: ±0.02% F.S
• Zero Balance: ±1% F.S
• Operating Temperature: -30 to +70℃
• Maximum safe overload: 150% OF R.C
• Maximum Excitation: 15V DC
• Environment Protection: IP68
• Input Impedance: 750±10Ω
• Output impedance: 702±3Ω; 703±5Ω(cable≥15m)
• Creep error: ±0.02% F.S
